Description
Electrical Parameters
|
Characteristics
|
Specification
|
|---|---|
|
Impedance
|
50 Ω
|
|
Operating frequency
|
DC to 2.5GHz
|
|
Insulation Resistance
|
≥5000MΩ
|
|
Withstand Voltage
|
1000V rms
|
|
VSWR
|
≤1.3 @ 2.5GHz
|
Cable Attenuation
|
Frequency
|
dB/100ft
|
dB/100m
|
Avg. Power Rating (Kw)
|
|---|---|---|---|
|
30 MHz
|
0.67
|
2.20
|
3.33
|
|
50 MHz
|
0.88
|
2.90
|
2.57
|
|
150 MHz
|
1.52
|
5.00
|
1.47
|
|
220 MHz
|
1.86
|
6.10
|
1.20
|
|
450 MHz
|
2.71
|
0.83
|
0.83
|
|
900 MHz
|
3.90
|
12.80
|
0.58
|
|
1500 MHz
|
5.12
|
16.80
|
0.44
|
|
1800 MHz
|
5.67
|
18.60
|
0.40
|
|
2000 MHz
|
5.97
|
19.60
|
0.37
|
|
2500 MHz
|
6.77
|
22.20
|
0.33
|
|
5800 MHz
|
10.82
|
35.50
|
0.21
|
Environmental Details
|
Parameter
|
Specification
|
|---|---|
|
Temperature range
|
-45 °C to +85 °C
|
|
Degree of protection (mated pair)
|
IEC 60529, IP68 （20℃,1m,24H）
|
|
RoHS compliant
|
RoHS compliant
|
